Humidifier System

Advanced ultrasonic and high-pressure humidifier systems that maintain the precise relative humidity essential for healthy mushroom growth and maximum yield.

Mushroom Production Plants

Humidifier System (Maintain Proper Humidity)

SHAKTI INDUSTRIES | Concept to Commissioning

Humidifier Systems for Mushroom Cultivation

SHAKTI INDUSTRIES supplies precision Humidifier Systems designed to maintain the high relative humidity levels essential for mushroom cultivation. Maintaining 85%–98% RH consistently throughout the growing room is critical for pin formation, fruiting body development, and preventing surface cracking of mushrooms.

We supply ultrasonic, high-pressure fogging, and steam humidification systems — each suited to different room sizes, temperature ranges, and integration requirements. All systems are PLC-controlled with proportional humidity sensors for precise RH management.

Applications: Mushroom growing rooms, casing rooms, spawn running rooms, ripening chambers, cold storage, greenhouse humidity control, and any space requiring precise RH management.

Humidifier Technologies

We offer three main humidification technologies, each with distinct advantages depending on your room size, temperature, and water quality.

Ultrasonic humidifiers (cold fog, energy-efficient)
High-pressure fogging systems (0.5–10 micron droplets)
Steam humidifiers (hygienic, sterile output)
Centrifugal atomizers (high capacity rooms)
Evaporative humidifiers (low-cost option)
In-duct steam distributors (AHU integration)

Why Choose SHAKTI Humidifier Systems?

Precise RH control ±2% accuracy
PLC-integrated with automatic on/off
No wet spots or visible water droplets
Hygienic design — no bacterial growth risk
Low energy consumption (ultrasonic preferred)
Easy maintenance — removable transducer trays

Our ultrasonic humidifiers produce a fine cold fog at 1–5 micron droplet size that evaporates instantly without wetting surfaces — maintaining uniform RH throughout the room without risk of disease promotion.

Technical Specifications

Humidifier TypeUltrasonic / HP Fogging / Steam
Capacity Range1 kg/hr – 100 kg/hr
Humidity Range60% – 99% RH
Control Accuracy±2% RH
Droplet Size1–5 microns (ultrasonic)
Water QualityRO / DM water recommended
Power Consumption0.5–3.5W per W of humidification
ControlPLC with humidity sensor (4-20mA)
Sensor TypeCapacitive RH sensor (±2% accuracy)
MaintenanceMonthly transducer cleaning

Humidity Control & Integration

Measuring Functions
  • Room Relative Humidity (%RH)
  • Room Temperature (for RH compensation)
  • Water Level in Reservoir
  • Water Conductivity
  • Humidifier Power Consumption
Controlling Functions
  • RH Setpoint Per Growing Stage
  • On/Off Hysteresis Band
  • Water Auto-Fill
  • Low Water Alarm
  • High RH Override
