PUF Panel Structure

Precision-engineered Polyurethane Foam (PUF) insulated panels — the backbone of energy-efficient mushroom cultivation rooms.

Mushroom Production Plants

PUF Panel Structure

SHAKTI INDUSTRIES | Concept to Commissioning

PUF Insulated Panel Structures

SHAKTI INDUSTRIES manufactures high-performance Polyurethane Foam (PUF) Insulated Panel Structures for mushroom growing rooms, cold rooms, ripening chambers, and composting tunnels. Our panels provide superior thermal insulation with excellent structural rigidity and long service life.

Our CFC-free PUF panels are available in 80mm, 100mm, 120mm, and 150mm thicknesses with GI or SS facings, and are engineered for airtight modular assembly that minimizes thermal bridging and condensation.

Applications: Mushroom growing rooms, composting tunnels, ripening chambers, cold rooms, freezer rooms, pharmaceutical cold storage, and food processing facilities.

Panel Features & Construction

Our PUF panels are manufactured under controlled factory conditions using high-pressure injection foaming for consistent density and excellent adhesion to facings.

CFC-free PUF core density 38–42 kg/m³
GI / SS 304 single or double facing
Cam-lock & tongue-and-groove joint systems
Thermal conductivity λ = 0.022 W/mK
Fire-retardant additive options
Modular prefabricated assembly

Why Choose SHAKTI PUF Panels?

Superior thermal performance (low U-value)
Lightweight for easy site installation
Airtight cam-lock joint system
Corrosion-resistant steel facings
Easy to clean hygienic interior surface
Custom sizes & thickness on request

Technical Specifications

Panel Thickness80mm / 100mm / 120mm / 150mm
Core MaterialCFC-free Polyurethane Foam (PUF)
Core Density38–42 kg/m³
Thermal Conductivityλ = 0.022 W/mK
U-Value (100mm)Approx. 0.22 W/m²K
Facing OptionsGI 0.5mm / SS 304 0.5mm / PP
Joint SystemCam-lock / Tongue & Groove
Panel WidthStandard 1000mm / 1200mm
Panel LengthUp to 6000mm (custom available)
Fire RatingB2 / B1 (FR grade available)

Panel Selection Guide

Thickness vs. Application
  • 80mm – Chilled rooms (+2°C to +10°C)
  • 100mm – Cold rooms (0°C to +5°C)
  • 120mm – Freezer rooms (-18°C to -25°C)
  • 150mm – Deep freeze / blast (-35°C to -40°C)
  • 80mm – Mushroom growing rooms
Available Facing Finishes
  • Pre-painted GI (standard)
  • Stainless Steel 304
  • Aluminium facing
  • PP liner (food-grade)
  • Embossed / smooth finish
